LCP substrate sputtering anti EMI coating

LCP substrate is a high-performance plastic material with low dielectric constant, low dielectric loss, high frequency, high temperature and other characteristics. It has excellent mechanical properties, chemical stability, and electrical insulation properties, and is widely used in fields such as electronic products and communication equipment. In these fields, the EMI (electromagnetic interference) shielding performance of LCP substrates is also particularly important. In order to improve the EMI shielding performance of LCP substrate, the LCP substrate sputtering anti EMI coating technology is often used. This article will provide a detailed introduction to the anti EMI coating technology for LCP substrate sputtering.

1、 Characteristics of LCP substrate

1. The dielectric constant of LCP substrate with low dielectric constant is much lower than that of general plastic materials, making its signal transmission ability better at high frequencies.
2. The low dielectric loss of LCP substrate results in relatively low dielectric loss, which enhances its signal transmission capability at high frequencies and reduces energy loss during signal transmission.
3. The high-frequency characteristics of LCP substrate are excellent and can meet the requirements of high-speed data transmission.

4. The high-temperature resistance of LCP substrate is excellent, and it can maintain stable performance in high-temperature environments.


2、 The EMI shielding performance of LCP substrate is particularly important in fields such as electronic products and communication equipment.
Electromagnetic radiation can cause interference and damage between electronic devices. Therefore, measures must be taken to protect the equipment from the impact of EMI. In this case, the EMI shielding performance of LCP substrate is very important. The EMI shielding performance of LCP substrate is related to its conductivity. Therefore, the EMI shielding performance of LCP substrate can be improved by coating conductive materials on its surface. The LCP substrate sputtering anti EMI coating technology is a commonly used method.

3、 LCP substrate sputtering anti EMI coating technology

1. Sputtering technology is a very common thin film coating technology, which prepares thin films by evaporating and depositing solid materials on the surface of the substrate under vacuum conditions. In this process, the material is heated to high temperatures to produce evaporated atoms or ions. These atoms or ions pass through the vacuum chamber and deposit on the surface of the substrate, forming a thin film layer.

2. Sputtering anti EMI coating technology for LCP substrate is a technique of depositing conductive materials on the surface of LCP to improve its EMI shielding performance. In this technique, the sputtering target material is prepared and placed in a vacuum chamber. Then, electronic guns, ion beams, and other devices are used to heat and sputter the target material, causing it to evaporate and deposit on the surface of the LCP substrate, forming a conductive thin film layer. Common sputtering target materials include copper, silver, nickel, aluminum, and other materials. Among them, copper is the most commonly used material because it has good conductivity and chemical stability.
