Introduction to the use of Nitto tape, worth collecting

Based on core technologies such as adhesive technology and coating technology, Nitto Denko adds various functions to film and sheet materials, and produces and sells polymer products with a wide range of applications in factories around the world, such as liquid crystal display optical films, automotive parts, seawater desalination films, transdermal absorption drug delivery patches, etc. Below we will introduce the common uses of Nitto tape:

Usage of some tape in the eastern part of Japan

Representative model:

【 No.5919M 】 【 No.5680W 】 【 CS-9611 】

【 No.581 】 【 No.5603 】 【 No.5915 】

【 No.5000NS 】 【 No.53100 】 【 No.5011N 】

【 No.501L 】 【 No.507 】 【 No.525B 】

[PF-370] [No.509A] [No.5091]

【No.5305W】【VR-5311、VR-5321】

【HJ-0240、HJ-9210】

【TW-Y01 No.5302A】

【 No.535A 】【 No.511 】【 No.513 】

【 No.501K 】 【 No.554 】 【 No.510 】

【 No.500 】 【 No.5015 】 【 No.532 】

【 No.541 】 【 No.5713 】 【 No.575 】

01

Heat resistant double-sided adhesive tape No.5919M

Double sided adhesive tape without substrate material, high heat resistance and strong adhesive strength.

The peeling layer uses a ceramic coating with high heat resistance. It has good heat resistance and can be used for welding operations even without peeling off the peeling layer.

We also have products with double-sided peeling layers available.

• Used for fixing FPC and reinforcing board • Used for fixing frame and FPC

02

Double sided adhesive tape for shading and reflection No.5680W

Using black and white special matrix materials, the white part hardly absorbs light.

It is a special matrix material with excellent light shielding properties.

Adhesives can exhibit high adhesion performance to various adhesives.

Fixed LCD and backlight illumination source

Backlighting LED for shading and fixing purposes

03

Transparent double-sided adhesive tape CS-9611

Ultra thin adhesive with excellent transparency.

It will not damage the appearance even when used in light, high temperature, and high humidity environments.

Suitable for bonding polycarbonate and other plastics.

Production and manufacturing are carried out in a clean room.

• Used for pasting functional films (optical films) onto display panels

Use this tape between glasses

04

Heat resistant double-sided adhesive tape No.581 for installation process

In the SMT process, the printed circuit board can be temporarily firmly fixed, easily peeled off after the project is completed, and can be reused repeatedly.

After pasting this double-sided adhesive tape, it can be transported and easily peeled off from the transport support plate after transportation.

Both the base material and adhesive have good heat resistance, and are also suitable for melting back into the furnace for processing.

• The printed circuit board for SMT process can be firmly fixed and reused repeatedly

05

Thin double-sided adhesive tape No.5603

There is a matrix material that demonstrates excellent processability.

Due to its thin adhesive tape, it can be used for adhesive purposes in limited locations.

The light pressure adhesion and adhesion performance to rough surfaces are both good.

• Used for LCD components

• Used for backlighting components

06

Heat resistant double-sided adhesive tape No.5915

Double sided adhesive tape without using substrate material, with excellent heat resistance and drug resistance.

High adhesive strength, excellent mechanical strength, and high reliability.

The amount of gas volatilization is extremely low.

• Used for fixing FPC

• Other aspects and heat-resistant applications

• Used for microfabrication operations

07

Double sided adhesive tape No.5000NS

Due to the strong toughness of the tape, there is no need to carry out the cumbersome operation of removing the tape after material damage.

Using adhesive with minimal residue.

• Has excellent adhesion performance.

Adhesive materials for buffering and sealing of office machines such as printers and copiers, as well as household appliances such as televisions and air conditioners.

Adhesive bonding between internal components of mobile phones, computers, and other devices and PET films

• Recycling and reuse of rubber rollers

08

Thick double-sided adhesive tape No.53100

Can maintain a stable shape and easily determine the position during pasting operations.

Can be tightly adhered to various dust-proof boards.

Compared with double-sided adhesive tape made of non-woven fabric substrate material, the uniformity of tape thickness is better.

LCD buffer material for fixed mobile phones and digital cameras

Fixed digital camera nameplate

09

Flame retardant double-sided adhesive tape No.5011N

• Has excellent initial adhesion.

Has excellent adhesion to rough surfaces.

The construction performance is also good at low temperatures.

It is a flame retardant qualified product that has obtained UL-94 VTM-0 certification.

Materials for components of electronic devices such as office machines and household appliances

Interior decorative materials for automobiles, trains, and airplanes

• Other aspects and bonding of flame-retardant materials

10

Double sided adhesive tape No.501L

Has excellent adhesion to rough surfaces.

Excellent low-temperature adhesion and stable performance even in winter.

• It has excellent resistance to rejection and can also prevent the floating of curved foam body.

• For pasting various foam bodies

• For pasting polyurethane foam plastics, etc

11

No.507 suitable for bonding concave convex surfaces

It is a thick adhesive tape with excellent adhesion to rough surfaces.

It also exhibits good adhesion at low temperatures and can maintain stable performance even in winter.

• For pasting various foam bodies

Used for pasting uneven surfaces such as wood

12

No.525B with excellent weather resistance

Excellent weather resistance, and its characteristics are not affected by climate changes.

The adhesive layer is thick and has good contact with rough surfaces.

Temporary fixation and joining of metal plates and outer wall materials

Around the window frame (for rain protection between the window frame and the outer wall, etc.)

13

PF-370 for temporary fixation of building materials

Rich in softness and excellent adhesion to rough surfaces.

• Has excellent initial adhesion.

Excellent adhesion can fully maintain and fix its shape before hardening.

• Excellent low-temperature adhesion.

Temporary fixing of interior decoration materials, etc. in residential buildings

14

Water soluble double-sided adhesive tape No.509A

The adhesive, substrate material, and release layer material are all water-soluble.

• Has excellent initial adhesion.

• Used for automatic splicing in papermaking processes

15

No.5091 with excellent adhesion to rough surfaces

The adhesive, substrate material, and release layer material are all water-soluble.

• Has excellent initial adhesion.

Has excellent adhesion to rough surfaces.

• Used for manual splicing in papermaking processes

• Splicing for ultra large scale rolling processes

• Splicing for resin coating process

• Splicing during roll change

16

UV coated double-sided adhesive tape No.5305W

• Has excellent pressure and adhesion.

• Excellent impact resistance.

UV coating does not require masking.

• Adhesive purpose for carrying mobile phone panels and UV coated frames

17

VR-5311 for fixed rubber VR-5321

Suitable for bonding vulcanized rubber such as chloroprene and EPT, as well as metals and plastics.

The filling process on the rubber surface can be cancelled.

The special adhesive used for VR-5311 rubber has excellent cohesion.

The special adhesive used for VR-5321 rubber has excellent initial adhesion.

Vulcanized rubber cushioning material used for household appliances, office machines, etc

• For bonding and temporary fixation of filling materials

18

Super strength HJ-0240 HJ-9210

Good adhesion, heat resistance, and retention.

Excellent adhesion strength to metal surfaces.

• Used for fixing metal plates

• Used for fixing metal reinforcement ribs

19

Double sided adhesive tape TW-Y01 for plastic and foam body

• Not only for metal, but also for polypropylene and other plastic materials, foam body and other rough surfaces.

• Has excellent resistance to rejection.

• Adhesion of plastic and foam

20

Silicone rubber adhesive No.5302A

Using silicone series adhesives that can adhere well to silicone rubber and have excellent electrical insulation properties.

Using acrylic series adhesives that can exert excellent adhesion to metal plates, plastic plates, and other adhesives.

Adhesive use of silicone rubber

21

Fixed resin printing plate No.535A

Using polyester film as the support, the adhesion between the front and back surfaces is different.

When peeling off the adhesive tape from the resin printing plate, there are almost no remaining fragments of the tape.

When bonding resin printing plates to the cylinder or printing table of a rotary machine, use it

22

Fixed printing plate No.511

High strength and not easily damaged.

The tape is not easily damaged during peeling.

Fixed resin printing plates

When drilling holes in metal nameplates, use

Fixed decoration for car price plates and air conditioners, etc

Adhesive for ABS decorative panels

Fixed plastic signs

23

Multi purpose double-sided adhesive tape No.5015

Mainly able to exert stable adhesion to various adhesives such as metal and plastic.

From low temperature to high temperature, it can be used under a wide temperature range.

• Excellent resistance to rejection.

• The nameplate and foam body can continue to play a fixed role although they have little power

Double sided adhesive tape with excellent processability No.532

It can exert stable adhesion to various adhesives such as metal and plastic.

From low temperature to high temperature, it can be used under a wide temperature range.

• Excellent resistance to rejection.

Adhesive for nameplates, dials, wiring boards, etc

For temporary installation of rivets, bolts, and small parts

• Used for fixing plate making and printing boards

24

Flexible double-sided adhesive tape No.541

Rich in softness, it also has excellent adhesion to relatively rough surfaces.

It also shows good adhesion at low temperatures and can be used for outdoor pasting operations in winter.

High adhesive strength, thus able to resist sudden impact forces.

Fixed interior panels for various vehicles and ships

• Used for maintaining various household items • Used for fixing various building materials

25

No.5713 with excellent durability

• Soft thin layer foam body is used, which has good contact with the adhesive and shows strong adhesion.

Has excellent holding power and can be stably fixed.

• Because the base material uses a thin layer of foam, it will give a feeling of integration with the adhesive after pasting.

• Fixing of various nameplates

• Fixing of car signs

As a label sealing material for precision instruments, etc

26

No.575 with excellent retention function

• The base material is foam type material, which has good adhesion to the adhesive.

• The base material is foam type material, which can exert excellent retention.

Used for fixing various hangers and placing hanging boards at home.

Fixed hangers and hanging boards for household use

Installation of small electronic components

• Fixed for various nameplates and models
