Application of LCP non-woven fabric with gold plating, copper plating, and nickel plating in consumer electronics

LCP non-woven fabric gold-plating LCP non-woven fabric copper plating The application of nickel plating in consumer electronics. For 3D stereo circuits, LCP material benefits from its aromatic structure and has excellent heat resistance. In the design of 5G antennas, LCP material has excellent electrical characteristics, good consistency, very low tangent loss and thermal expansion characteristics, and can be used as an ideal high-frequency packaging material

⑴ Can be used in product environments that require high heat resistance at 300 ° C

In environments below 300 ° C, the shrinkage rate is also less than 1%, and the product has almost no deformation, making it particularly suitable for masking tapes or gaskets in SMT and other processes.

⑵ Suitable for Foldable products that require heat resistance

When folding products, there are no worries like in Film

⑶ Apply heat-resistant adhesive directly onto non-woven fabric, using heat-resistant tape, especially when used in curved areas for the best effect.

Due to its low heritability (2.7), it can be used in 5G bandwidth of 3GHz, 5GHz, and 28GHz in the future. It can be used in the same area as F-PCB for fast transmission without loss of information.

⑸ Strong chemical resistance, not easily contaminated by other substances, and will not oxidize

⑹ It is an absorbent product that will not affect electrical performance even if it is used for a long time.

LCP fiber itself has strong tensile strength and is produced by Melt Blown method, which is quite high in tensile strength compared to products from other companies Non woven fabric manufacturing does not use adhesives, electrical conductivity after gold plating
