Application of four common metal conductive powders in the industry

Nano silver conductive powder（Ag99.99%）
1) Flake silver powder:
Common particle size:< 1um, 1-3um, 3-5um, 5-8um, 10um, particle size distribution and loose density can be customized according to requirements. We can provide low porosity flake silver powder.
Appearance: Silver gray with metallic luster
Application: Flake silver powder is a high-performance conductive filling material with good oxidation resistance. Flake silver powder is the main raw material for making conductive coatings, film switches, conductive inks, conductive rubber, conductive plastics, conductive ceramics, etc.
Flake silver powder is very good Low temperature polymer slurryIdeal raw materials for conductive coatings, conductive paints, and electromagnetic shielding coatings. The coating prepared with flake silver powder has good fluidity, anti settling, and a large spraying area.
2) Spherical silver powder:
Common particle size:< 1um, 1-3um, 3-5um, 5-8um, 10um, particle size and parameters can be customized according to requirements.
Application: Near spherical silver powder is mainly suitable as a conductive filler for high-temperature sintered silver paste.
There is no absolute standard for the superiority or inferiority of silver powder as a conductive filler. The selection of silver powder should be based on the corresponding binder, the public welfare of the target conductor material, the physical and chemical properties of the film layer, and the requirements for reliability.
2. Silver copper conductive powder (commonly with particle sizes of 1-3um, 3-5um, 5-8um, 10um, and Ag content ranging from 3% to 35%)
characteristic:
1) Silver coated copper powder has a small particle size, which can reach the sub micron level.
2) Silver coated copper powder has various shapes, including spherical, flaky, and dendritic.
3) Silver coated copper powder has excellent conductivity and lower cost, and can replace some application areas of silver powder.
4) Silver coated copper powder has good oxidation resistance and dispersibility, and can be applied to medium and low temperature slurries.
Application scope: It can be widely used in conductive adhesives, conductive coatings, polymer slurries, and various microelectronics technology fields that require conductivity and static electricity, electromagnetic shielding, non-conductive material surface metallization treatment, and other industries.
Silver coated copper powder can be widely used in conductive adhesives, conductive coatings, polymer slurries, and various microelectronics technology fields that require conductivity and static electricity, as well as in industries such as surface metallization of non-conductive substances. It is a new type of conductive composite powder.
Silver coated copper conductive paint is widely used in the fields of conductivity and electromagnetic shielding in various industries such as electronics, electromechanical, communication, printing, aerospace, and military. Products such as computers, mobile phones, integrated circuits, various electrical appliances, electronic medical equipment, electronic instruments, etc. are not affected by electromagnetic wave interference, while reducing the harm of electromagnetic radiation to the human body. In addition, conductive treatment of insulators such as colloids and circuit boards ensures that insulated objects have good conductivity.
3. Ultra fine pure copper powder (Cu 99%)
Common particle size:< 1um, 1-2um, 5-8um, etc.
Features: spherical shape, uniform particle size, good dispersion, high crystallinity
Application scope of nano copper powder: manufacturing terminals and internal electrodes of multi-layer ceramic capacitors, electronic components, and electronic pastes.
4. Pure nickel powder (Ni 99.9%)
Common particle size: 1-3um

Nickel powder, as a functional conductive filler, can be added to coatings, adhesives, inks, plastics, rubber to make conductive, electromagnetic shielding, anti-static and other products. It is widely used in various industrial sectors such as electronics, electromechanical, communication, printing, aerospace, weapons, etc. Electromagnetic shielding and anti-static measures for electronic, electrical, and communication products such as computers, mobile phones, electronic medical equipment, and electronic instruments.

Silver coated Copper PowderAlso known as silver coated copper powder, it is mainly used for shielding materials and conductive adhesives. Due to the different parameter requirements of each customer, Advanced Institute Technology supports customer customization. Our company can customize dendritic silver foil copper powder, spherical silver foil copper powder, and flake silver foil copper powder. Common silver contents include 3%, 5%, 7%, 10%, 15%, 20%, 25%, 30%, etc.

The particle size of silver coated copper powder can be selected from various sizes ranging from 1um to 100um. Customers can provide their D50 and D90 requirements.
