FPC soft board for blood glucose meter

The FPC soft board of the blood glucose meter is an electronic component manufactured using flexible printed circuit board technology, which has the characteristics of being thin, flexible, and high-density wiring. It is usually installed inside the blood glucose meter, responsible for connecting key components such as sensors, processors, and display screens to achieve accurate collection and transmission of blood glucose data.

Product Features

1. Lightweight and bendable:

   • The FPC soft board of the blood glucose meter adopts a flexible substrate, which has the characteristics of being thin, light, and bendable, and can adapt to the complex spatial layout inside the blood glucose meter, improving the overall integration and portability of the equipment.

2. High precision design:

   • The FPC soft board of the blood glucose meter adopts high-precision manufacturing technology to ensure the stability and reliability of the circuit connection. It can accurately transmit blood glucose data, improving the measurement accuracy and precision of the blood glucose meter.

3. Excellent electrical performance:

   • The FPC soft board of the blood glucose meter has good electrical performance, including low impedance, high insulation resistance, etc., which can ensure stable transmission and processing of blood glucose data.

4. Good biocompatibility:

   • The FPC soft board of the blood glucose meter adopts special materials and processes in the manufacturing process to ensure its good biocompatibility. This allows it to remain safe and harmless when in contact with human skin or blood.

5. Waterproof and dustproof design:

   • The FPC soft board of the blood glucose meter usually adopts a waterproof and dustproof design, which can maintain stable performance in humid or dusty environments. This helps to extend the lifespan and reliability of the blood glucose meter.

application area

The FPC soft board of the blood glucose meter is mainly used in medical equipment such as blood glucose meters to collect, transmit, and process blood glucose data. It is suitable for home self-test, hospital diagnosis and other scenarios to provide convenient blood glucose monitoring services for diabetes patients.

Structure and Materials

The FPC soft board of a blood glucose meter usually consists of the following parts:

1. Substrate: Made of flexible materials such as polyimide or polyester, it has good flexibility and temperature resistance.

2. Copper foil: attached to the substrate to form a conductive path. The thickness and width of copper foil can be adjusted as needed to meet different circuit design requirements.

3. Cover film: used to protect circuits from external interference and damage. Covering film is usually made of materials such as polyimide or polyester, which have good insulation and wear resistance.

4. Adhesive: Used to bond copper foil and cover film components together to form a complete circuit structure. Adhesives need to have good bonding strength and temperature resistance.

Production process

The production process of the FPC soft board for blood glucose meters includes multiple steps such as cutting, drilling, electroplating, graphic transfer, etching, testing, covering film bonding, lamination, punching, electroplating, and testing. Each step requires strict control of process parameters and quality requirements to ensure the performance and reliability of the final product.

In summary, the FPC board of a blood glucose meter is an electronic component with the characteristics of being thin, flexible, and designed with high precision. It plays an important role in medical equipment such as blood glucose meters. It has a wide range of applications and complex production processes, requiring strict control of quality requirements and process parameters.
